- Plasma 6 HMX Carbon Fork
- Plasma 6 HMX Carbon Frame
- SRAM RED AXS Disc 24 Speed
- Syncros Capital SL Aero 80mm Wheels
- Schwalbe PRO ONE Aero TL Tires
- Syncros Carbon parts
- Model: 423296
Frame
Plasma 6 HMX
TRI Geometry / Plasma HMX seat post / Replaceable Derailleur Hanger
Fork
Plasma 6 HMX
1 1/4"- 1 1/2" Carbon
Flat mount Disc
Rear Derailleur
SRAM RED AXS
24 Speed
Electronic Shift System
Front Derailleur
SRAM RED AXS
Electronic Shift System
Shifters
SRAM eTap AXS Wireless Blips
Crankset
SRAM RED AXS Power meter
48/35 T
BB-Set
SRAM DUB PF ROAD 86.5
Chain
SRAM RED
Cassette
SRAM RED XG 1290 E1
10-30
Brake Levers
SRAM S-900 Aero HRD
Brakes
SRAM S900 HRD flat mount
Rotor
SRAM PACELINE X rotor 160/F and 160/R
Handlebar
Syncros Creston iC TRI
400mm
Syncros E1 Carbon extension
Seatpost
Syncros Plasma 6 HMX with Ritchey WCS clamp
adjustable head
Seat
Syncros Belcarra 1.0 TRI
Headset
Syncros Integrated
1 1/4"- 1 1/2" drop-in headset
Wheelset
Syncros Capital SL Aero 80mm
Syncros SL Axle / Removable Lever with Tool
Front Tire
Schwalbe PRO ONE Aero
TL-Easy
Fold
700x28C
Schwalbe Aerothan tube
Rear Tire
Schwalbe PRO ONE Aero
TL-Easy
Fold
700x28C
Schwalbe Aerothan tube
Approx weight in KG
9.2
Approx weight in LBS
20.28
Max. System Weight
120kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage
Back Wheel Adjustability
The closer the tire is to the seat tube, the more aero it is. In contrast to the front end, the back wheel is always aligned with the seat tube. To give every rider the chance to ride the most aerodynamic position, no matter the wheel or tire choice, you have 6 different wheel mount positions.
Down Tube Position
The most aerodynamic, optimized position of the down tube would be directly behind the front tire, but the slightest of movements in the front wheel would already create strong turbulence and significantly increase the drag. Extensive testing revealed that the second-fastest position is to have a significant gap between the front tire and the down tube, which makes it the fastest one in real-life conditions.
Storage Integration
The Plasma 5 was already ahead of its competitors when it comes to storage integration. The new Plasma 6 reaches an even higher level. It allows you to store all your spare parts and nutrition inside the frame design. The new hydration system also makes it possible to stay in the aero position during hydration and nutrition intake, plus it makes it easy to refill on the fly.
