- KEY FEATURES
- SPECIFICATIONS
- GEOMETRY
- Addict RC Disc HMX Carbon Frame
- Addict eRIDE HMX Fork
- Shimano Ultegra/105 22 Speed
- Mahle Motor Hub drive 55Nm max Torque, up to 425Wh
- Syncros Capital 2.0 25e Disc Wheels
- Schwalbe One Tires
- Syncros Carbon/Alloy parts
- Model: 286541 / 286545
FRAME
Addict eRIDE Disc HMX
Endurance geometry / Replaceable Derailleur Hanger
Fully Internal cable routing
Range Extender Ready
FORK
Addict eRIDE HMX Flatmount Disc
1 1/4"-1 1/2" Eccentric Carbon steerer
DRIVE UNIT
Mahle X20 Motor Hub drive 55Nm max Torque / EU: 25kmh / US: 20mph
BATTERY
Mahle 36V-250Wh
DISPLAY
Mahle One
Bluetooth / Dedicated Smartphone app
CHARGER
Mahle 100-240V-4A
REAR DERAILLEUR
Shimano Ultegra RD-R8000-GS
22 Speed
FRONT DERAILLEUR
Shimano 105 FD-R7000
SHIFTERS
Shimano 105 ST-R7020 Carbon
Dual control 22 Speed
CRANKSET
Shimano 105 FC-R7000
Hollowtech II 50x34 T
BB-SET
Shimano SM-RS500-PB
CHAIN
Shimano 105 CN-HG601-11
CASSETTE
Shimano CS-R7000
11-32 T
BRAKES
Shimano BR-R7070 Hyd.Disc
ROTOR
160/F SM-RT800 CL and 160/R SM-RT76 6B rotor
HANDLEBAR
Syncros Creston 2.0 Compact
Alloy
H'STEM
Syncros RR iC
1 1/4"
SEATPOST
Syncros Duncan 1.0 Aero
SEAT
Syncros Belcarra Regular 2.0
HEADSET
Syncros Addict RC Integrated
WHEELSET
Syncros Capital 2.0 25e Disc
24 Front 12x100mmTA /32 Rear 12x142mmTA
FRONT TIRE
Schwalbe ONE Race-Guard Fold
700x30C
REAR TIRE
Schwalbe ONE Race-Guard Fold
700x30C
APPROX WEIGHTS IN KG 11.90
APPROX WEIGHTS IN LBS 26.23
MAX. SYSTEM WEIGHT 120 kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
