- KEY FEATURES
- SPECIFICATIONS
- GEOMETRY
- Genius Carbon HMF-Alloy Frame
- FOX 36 Float Perf. Elite 160mm Fork
- FOX Nude 5T EVOL, TwinLoc, 150mm
- SRAM GX Eagle AXS 12 Speed
- Shimano XT 4 Piston Disc Brakes
- Maxxis Foldable Tires
- Model: 290139 / 290144
FRAME
Genius Carbon HMF Mainframe with Alloy 6061 Swingarm
Integrated Suspension Technology
Virtual 4 Link kinematic / Adjustable head angle
Syncros Cable Integration System
BB92 / UDH Interface / 12x148mm with 55mm Chainline
FORK
FOX 36 Float Performance Elite Air FIT4
3-Modes with low Speed adj. / Kabolt 15x110mm axle
44mm offset / tapered steerer / Reb. Adj. / Lockout
160mm travel
REAR SHOCK
FOX NUDE 5T EVOL Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Custom large Air volume / DPS / Reb. Adj.
Travel 150-100-Lockout / T185X55mm
REMOTE SYSTEM
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes
REAR DERAILLEUR
SRAM GX Eagle AXS 12 Speed
Wireless Electronic Shift System
SHIFTERS
SRAM GX Eagle AXS Rocker Controller
CRANKSET
SRAM GX Eagle DUB
55mm CL / 32T
CHAINGUIDE
SCOTT custom
BB-SET
SRAM DUB PF 92 MTB Wide / shell 41x92mm
CHAIN
SRAM CN GX Eagle
CASSETTE
SRAM XG1275 / 10-52 T
BRAKES
Shimano XT M8120 4 Piston Disc
ROTOR
Shimano SM-RT76 / 6 Bolt / 203/F and 180/R
HANDLEBAR
Syncros Hixon iC Carbon
Size S & M 15mm rise / Size L & XL 25mm rise
back sweep 8° / 780mm
Syncros Endurance lock-on grips
SEATPOST
Syncros Duncan Dropper Post 1.5
31.6mm / S size 140mm / M size 160mm / L size 170mm / XL size 200mm
SEAT
Syncros Tofino 1.5 Regular
Titanium rails
HEADSET
Syncros - Acros Angle adjust & Cable Routing HS System
+-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB
WHEELSET
Syncros Revelstoke 1.5 6 Bolt
F: 15x110mm, R: 12x148mm
30mm Tubeless ready rim 28H / XD Driver
Syncros Axle w/Removable Lever
with 6mm Allen, T30 and T25 Tools
FRONT TIRE
Maxxis Dissector / 60TPI Foldable
Tubeless Ready / EXO 3C maxx Terra
REAR TIRE
Maxxis Dissector / 60TPI Foldable
Tubeless Ready / EXO 3C maxx Terra
EXTRAS
SRAM AXS Powerpack
Syncros Fork Fender
APPROX WEIGHTS IN KG 14.1 (Tubeless setup)
APPROX WEIGHTS IN LBS 31.09 (Tubeless setup)
MAX. SYSTEM WEIGHT 128kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
