Scott Scale 10 SRAM AXS Gravel Bike

The Scale Gravel was put on this planet for going on adventures with attitude. Designed to go the distance over any and all types of terrain, the Scale Gravel is lightweight with agile handling and features multiple mounting options.

Please note that bike specifications are subject to change without prior notice.

• Scale Carbon HMF Frame

• Scale Rigid HMF Fork

• SRAM S1000 AXS Transmission 12 Speed Drivetrain

• SRAM DB6 4 Piston Disc Brakes

• Syncros X-28TR Rims

• Maxxis Aspen Foldable Tires

• Syncros Parts

• Frame: Scale Carbon HMF Adjustable head angle, Syncros Cable Integration System, Advanced Shock & Standing Damping System BB92, UDH Interface, 12x148mm with 55mm Chainline

• Fork: Scale Rigid HMF Postmount Disc Standard Tapered Carbon steerer
• Rear Derailleur: SRAM S1000 Eagle AXS Transmission 12 Speed Wireless Electronic Shift System

• Shifters: SRAM AXS Pod Controller
• Crankset: SRAM Eagle 70 Transmission DUB, 55mm CL, 34T

• Chainguide: SCOTT custom

• BB-Set: SRAM DUB PF 92 MTB Wide, shell 41x92mm

• Chain: SRAM CN Eagle 70 Transmission

• Cassette: SRAM Eagle XS 1270 V2 Transmission 10-52

• Brakes: SRAM DB6 4-Piston Disc

• Rotor: SRAM Centerline CL Rotors 180/F and 160/R

• Handlebar: Syncros Fraser 2.0 XC Alloy 6061 D.B. Flat Bar, 8°, 740mm, Syncros Performance XC lock-on grips

• H'stem: Syncros XC 2.0 Syncros Cable Integration System -12° rise, 6061 Alloy, 31.8mm, 1 1/8"
• Seatpost: Syncros Duncan 2.0, 10mm offset 31.6x400mm

• Seat: Syncros Belcarra V2.0 Cut Out CRMO rails

• Headset: Syncros - Acros Angle adjust & Cable Routing HS System +-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB

• Hub (Front): Formula CL-811, 15x110mm

• Hub (Rear): Formula CL-3248, 12x148mm

• Spokes: Stainless Black 15G, 1.8mm

• Rims: Syncros X-28, 28H, Tubeless ready

• Front Tire: Maxxis Aspen, 29x2.4", 120TPI Foldable Bead Tubeless Ready, EXO

• Rear Tire: Maxxis Aspen, 29x2.4", 120TPI Foldable Bead Tubeless Ready, EXO

• Extras: SRAM AXS Powerpack

• Accessories: Spirgrips+ Inner Bar ends

• Approx. weight in KG: 10.5 (Tubless setup)

• Approx weight in LBS: 23.15 (Tubless setup)

• Max. System Weight: 120kg. The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
• Product Code: 425491

Monocoque Construction -  The new Scale RC’s monocoque construction enables production using only one mold for the main section of the bike, the front triangle. Applying our carbon expertise, the new Scale therefore consists of only 3 separate pieces molded together. This directly translates into an increased level of efficiency due to the reduced number of junctions required therefore decreasing weight while keeping the superior stiffness – something we’re always aiming for with hardtail race bikes. With the full frame constructed as a system, the monocoque design enables the frame to handle forces as a whole.

Service Door - A little service door, which is accessible through a downtube cover, allows easy access to the interior of the frame without the need to remove the Bottom Bracket. Frame maintenance is made easy with regard to cable routing.

Hollow Dropout Construction - The dropout features an advanced, hollow construction, which allows the axle head to clamp against the inner surface of the dropout and leaves the head flush with the surface. This enables the lightest possible construction approach and a clean looking design from the outside. While being able to directly shave off 7.5g with the new dropout construction, the optimized design favors a narrower construction of the rear triangle area, which in turn enables a reduction of 20g in this area of the frame (HMX-SL).
